Conductive Foam Suitable for EMI Shielding and Absorbing Gaskets

Basic Info.

Model NO.	XLF
Standard	Standard, Nonstandard
Operating Temperature	-20 ~ +80tºC
Shape	Customizable
Shielding Effectiveness (at 100MHz~1GHz)	> 65tdb
Surface Resistance	< 0.08Ω
Transport Package	Carton
Specification	customizable
Trademark	Xinlongfei
Origin	China
HS Code	3926909090
Production Capacity	1000000/Day

Product Description

EMI gaskets with conductive fabric over foam core
Protect Electrical and Electronic Equipment With EMI Gaskets
EMI shielding fabric-over-foam gasket | EMI Shielding Gasket

Overview

• EMI shielding fabric-over-foam gasket is made of conductive fabric or metal foil for its cladding for EMI/RFI shielding and electrical surge grounding effects.
• Double-sided taping for easy attachment to objects, various shapes/sizes available
• Optimal for touch sensor gasket or touch switch gasket

• Specifications

  Shielding Effectiveness:> 85dB attenuation from 20 MHz to 10 GHz
  Electrical Resistance: < 0.05 Ohms/Sq
  Compression Deflection: < 1 lb/in
  15-19 percent
  Compression Set: 15 percent at 70 °F. (21 °C.)
  19 percent at 158 °F. (70 °C.)
  Service Temperature: -40 °F. (-40 °C.) to 158 °F. (70 °C.)

• Why grounding in electronic devices

• A. Ground includes signal ground, chassis ground (frame ground), and earth ground.
  In relation to electronic circuits, signal grounding is done to define the reference potential (0V) of circuits and systems, and chassis grounding prevents radiation of noise induced in a metal case or prevents electric shock caused by the case.

  Failure to the ground may cause malfunctions due to noise and unnecessary electromagnetic waves, so it must be considered during the design stage.
  Also, since the grounding part is contaminated and noise can reversely enter the circuit, series grounding, parallel grounding, single-point grounding, multi-point grounding, etc. must be applied.
  If the ground wire is long, it can act as an antenna that radiates electromagnetic waves, so the ground wire should be as short as possible.

  Depending on the frequency characteristics, a method using a capacitor or an inductor may be used.





  Features:
• RoHS Compliant, Halogen Free
• Flame retardant material (UL94V-0) used
• EMI shielding and electrical surge grounding function at the same time
• Excellent elasticity using PU sponge for core material
• Various lengths and shapes are available, and easy to die-cut or scissors cutting.

Specifications:

Contents	Unit	Data
		Fabric Type	Aluminum Foil Type
Surface resistance	Ω	< 0.08	< 0.05
Shielding effectiveness (at 100MHz~1GHz)	DB	> 65	> 65
Operating temperature	ºC	-20 ~ +80	-20 ~ +80
Recommended compression rate	%	25~30	10~15
Flame Retardancy	-	UL94V-0 * Only applicable type
Eco-friendly	-	RoHS Compliant, Halogen Free
Shape		1) Rectangular Shape 2)D Shape 3)O Shape 4) P Shape 5) Double P Shape 6) L Shape 7)C-fold Shape8)C-fold with PET film Shape 9)Knife Edge Shape 10) T Shape 11)U Shape 12)Small B Shape 13)Double Rectangular Shape 14) Bell Shape Shape
Surface		1)PET Ripstop + Cu, Ni2) PET Ripstop + Cu, Ni + ATU3)PET Taffeta + Cu, Ni4) PET D.T.Y. + Cu, Ni5)PET Taffeta + Cu, Ni + Carbon	1) PET Ripstop + Cu, Ni, Ag 2) PET Taffeta + Cu, Ni, Au 3)PET Ripstop + Cu, Ni + Carbon 4)Al Foil + PET Film + PET Fabric 5) Al Foil + PET Film

Shielding effectiveness

Applications

EMI Shielding & PCB Ground

• Fabric-Over-Foam Gasket is attached to the tuner part, PCB, cable, etc., for grounding with the external case.

Touch Sensor Gasket / Touch Switch Gasket

• Touch sensor gasket (touch switch gasket) functions as an electrode connecting the display panel and PCB in the electrostatic touch input method. It is mainly suitable for touch switches of home appliances and industrial devices.
• Hole processing in the center is available, so it could be attached over the LED light to return ON/OFF status when touched.
• The touch grid method is expensive, but the foam gasket is economical and workable in an adequate number of touch points.
• The gasket does not stress PCB/Panel due to its softness.
